Boss DB-90 Dr. Beat
Boss DB-90 Dr. Beat
Quick rhythm customizing with Note Mixing function, dozens of play-along drum patterns also built in Dedicated sliders, buttons, rotary dial,... Read more
- Free pickup in our shop(s)
$159.99
SKU: DB90
Size chart
Product Description
- Quick rhythm customizing with Note Mixing function, dozens of play-along drum patterns also built in
- Dedicated sliders, buttons, rotary dial, and large backlit LCD for user-friendly operation
- 4 metronome (including human voice) sounds
- Reference Tone function makes it easy to verify tuning by ear
- Practice with the Rhythm Coach by connecting a V-Pad (optional) — rubber pads and acoustic drums can also be detected via built-in mic
- Direct connection with guitar and bass, plus headphone monitoring
- Footswitch control for hands-free play/stop, and MIDI input for sync to external sequencers
- Metronome
- Tempo: 30-250 (Accuracy: ±0.1%)
BEAT: (BEAT1) 1–9, (BEAT2) OFF/1–9
PATTERN: 8-BEAT x 4, 16-BEAT x 3, SHUFFLE x 3, FUNK x 2, JAZZ x 2, BLUES, TECHNO, HOUSE, COUNTRY, REGGAE, CLAVE 3-2, CLAVE 2-3, SALSA, RUMBA, BOSSA NOVA, SAMBA, WALTZ, TANGO, MAMBO, CHACHACHA, MARCH (30 kinds) - RHYTHM COACH
- Time Check, Quiet Count, Gradual Up/Down, Step Up/Down
- Reference Tone
- Reference Pitch: A4=438 Hz-445 Hz (1 Hz steps)
Reference Tone Range: C2-B6 (5 octave, 12 semitone) - Memory
- Metronome: 50
Reference Tone: 10 - Auto Power Off function
- Turns unit off after 60 min
- Indicators
- LCD Display, Tempo Indicator LED x 2
- Connectors
- TRIG IN jack
START/STOP jack
MEMORY UP/DOWN jack
MIDI IN connector
PHONES jack x 2 (Stereo 1/4" phone type, Stereo miniature phone type)
INPUT jack
AC ADAPTOR jack - Power Supply
- DC-9V: Dry Battery (6LR61/9V, 6AM6/9V) or AC adaptor (PSA series)
- Current Draw
- 85 mA or less (with reference tone sounding)
190 mA or less (with signals input to the INPUT jack) - Accessories
- Dry Battery (6LR61 (9V) Type)
Soft case
Owner's Manual
Boss nut (M8) - Size and Weight ( incl. battery )
- Width
- 122 mm
4-13/16 inches - Depth
- 164 mm
6-1/2 inches - Height
- 38 mm
1-1/2 inches - Weight
- 450 g
1 lbs. - *The specifications are subject to change without notice.
