Product Description
The Pro-Mod Series continues upon Charvel’s storied legacy of innovative excellence in high-performance guitar design, offering the latest technology and top-notch features that modern players need. An ideal instrument for dazzling high-speed playing, the San Dimas Style 1 HH FR E boasts scorching sound, stunning style and grin-inducing playing feel and performance.
- Body: Alder
- Body Finish: Gloss
- Body Shape: San Dimas Style 1
- Control Knobs: Knurled Flat-Top
- Fingerboard: Ebony
- Hardware Finish: Chrome
- Pickguard: None
- Position Inlays: White Dot
- Neck Finish: Hand-Rubbed Satin Urethane
- Neck Construction: Bolt-On with Graphite Reinforcement
- Neck Shape: Speed Neck with Rolled Fingerboard Edges
- Neck Pickup: Seymour Duncan '59 SH-1N
- Side Dots: White
- Headstock: Licensed Fender Stratocaster
- Orientation: Right-Hand
- Configuration: HH
- Scale Length: 25.5" (64.77 cm)
- Number of Frets: 22
- Fret Size: Jumbo
- String Nut: Floyd Rose 1000 Series Locking
- Nut Width: 1.6875" (42.86 mm)
- Bridge Pickup: Seymour Duncan JB TB-4
- Controls: Volume (Push/Pull Coil Split), No-Load Tone
- Pickup Switching: 3-Position Blade: Position 1. Bridge Pickup, Position 2. Both Inner Coils, Position 3. Neck Pickup - (Split Engaged) - Position 1. Bridge Outer Coil, Position 2. Both Outer Coils, Position 3. Neck Outer Coil
- Pickup Configuration: HH
- Bridge: Floyd Rose 1000 Series Double-Locking Tremolo (Recessed)
- Tuning Machines: Charvel-Branded Die-Cast
- Strings: Nickel Plated Steel (.009-.042 Gauges)
- Case/Gig Bag: Optional Charvel Style 1/2 Economy Case (p/n 099-0912-100); Optional Charvel Multi-Fit Gig Bag (p/n 299-1414-006)
- Fingerboard Radius: 12"-16" Compound Radius (304.8 mm to 406.4 mm)
- Refinement Fingerboard Radius: Compound
- Neck Material: Maple
- Refinement Neck Material: Maple
- Nut Material: Floyd Rose 1000 Series Locking
- Truss Rod: Dual-Action with Wheel
- Truss Rod Nut: Heel-Mount Truss Rod Adjustment Wheel
